LAUNCH 440(440W) 455(455W) Installation Manual
24
No
Material code Name
301 104130231 Thin rubber pad
302 103201482 Cover assembly
303 104130232 Thick rubber pad
304 103201486 Left hand sliding adapter
305 103201488 Telescoping end welding seat
306 103050002 Returning ring 12
307 104990116 roller
308 103201495 axle
309 104990115 Outer arm slider
310 103201490 Safety pin
311 104990114 Inner arm slider
312 103201484 Safety rack I
313 103201485 Safety rack II
314 103201481 Seat assembly
315 104990115 Scissor arms
316 103201493 Cylinder pushing axle
317 104990114 Inner arm slider
318 103201494 Cylinder fixing axle
319 103260149 Cylinder
320 103060354 Pin 6X24 GB879-86
321 103990153 Air / hydraulic pump JIAKE65480
322 103020134
Allen bolt M6X15，GB/T5780-1986
323 103100187 Oil hose connector
324 103030098 Locking nut M8 GB/T889-1986
325 102990093 L type air hose connector APL8-02
