LAUNCH 440(440W) 455(455W) Installation Manual
27
No
Material code Name
401
201011348 Front wheel stop
402 103020073 Screw M10*20 GB/T5789-86
403 201020692 Short up cover
405 103201518 Turn table
406 201020713 440 Left runway
201021127 455 left runway
407 103201981 440 left Sheave
104990137 455 sheave
408 104990121 440 Spacer
104990138 455 spacer
409 201020696 440 Sheave pin assembly
201021132 455 Sheave pin assembly
410 201020695 Front ramp
411 103020073 Screw M10*20 GB/T5789-86
412 201011365 440 Clamp I
201012241 455 clamp plate
413 201011366 Clamp II
201012242 455 clamp
414 103201519 Cable I
103201929 455 cable I
103201520 Cable II
103201930 455 Cable II
103201521 Cable III
103201931 455 Cable III
103201522 Cable VI
103201932 455 Cable VI
415 103201513 440 Hydraulic cylinder
103260177 455 Hydraulic cylinder
416 103201502 Burst protection valve
417
103250168
Core of protection valve
418
103020073
Screw M10*20 GB/T5789-86
419
103201508
Pin of cylinder
420
103060356
Cotter pin 3.2*36 GB/T91-86
421
103201506
440 Axle of drive on ramp
201012246
455 Axle of drive on ramp
422
103020132
Screw M8*15 GB/T5789-86
423
104990120
Sheave bearing
103201982
440 left sheave non-oil bushing
103060356
455 non-oil bushing
425
103010498
Screw M5X8 GB/T 819-85
