LAUNCH X-431 PRO MINI User Manual
3
1
V
CI module
2
Reset hole
3
Rear camera
4
Camera flash
5
Slot for VCI module
For housing the VCI module.
6
POWER
/
Screen lock
key
In Off mode, press it to turn X-431 PRO
MINI on;
In On mode, turn X-431 PRO MINI off with
long press or lock screen with short press.
7
Carry strap
8
Air intake vent
9
USB
/
Charging port
To connect to the power adaptor for
charging.
10
Microphone
11
LCD screen
12
V
OLUME +
/
- Key
To adjust the volume. To print the screen,
hold and press the POWER and VOLUME –
key until a snapshot pops up on the screen.
The captured snapshot is saved in the
“Screenshots” folder.
13
Speake
r
14
Front camera
15
Earphone Jack
