LAUNCH X-431 V V4.0 User Manual
63
• Select the desired report and then tap “Delete” to delete it.
• To revise the filename of the report, tap “Rename”.
If user records the running parameters while reading data stream, it will be
saved as .x431 file and appear under Diagnostic Record tab.
Tap the desired one to enter. Select the desired data stream items and tap
“Confirm” to jump to the playback page:
On-screen Buttons:
Graph – displays the parameters in waveform graphs.
Value – this is the default mode which displays the parameters in texts and
shows in list format.
Combine – this option is mostly used in graph merge status for data comparison.
In this case, different items are marked in different colors.
Frame Playback – plays back the recorded data stream items frame by frame.
