SX205100A Dryer Controller
7. Parameter
Note: All parameters have already been configured for the machines in factory. Don’t intend to
modify any parameter without any special requirement. Some modification will lead to abnormal
work.
After power is on, the LCD shows the startup interface. Press [Set] button for 3 seconds during the 10
seconds counting down,then the LCD will ask you to input the passwords.
After enter the correct password, you can enter into parameters setting interface.
Default password is: [Up], [Down], [Up], [Down], [Down], [Up], [Down], [Up]
 Press [Down] or [Up] button to select setting item and press [Set] button to enter into the selected
item.
 After modification, press [Stop] button for 3 seconds to reserve the modified value and exit to the
idle page.
7.1. Parameter initialization
On the top menu Of parameter setup interface, press [Down] or [Up] button to select “1:Reset
data” and press [START] button to enter into this item.
Press [Down] or [Up] button to select “1: Reset paramet.” and press [Set] button to reset all the
parameters to default value.
Press [Down] or [Up] button to select “2: Reset program” and press [Set] button to reset all the
programs to default value.
Press [Stop] button to exit.
7.2. Machine parameter setup
On the top menu Of parameter setup interface, press [Down] or [Up] button to select “2:Machine
setup” and press [Set] button to enter into this item.
12/16
Input password-8
PARAMETERS
1:Reset data
2:Machine setup
<Stop>3S quit
1:Reset data
1:Reset paramet.
<Set> start
<Stop> quit
2:Machine setup
1:Fwd run time
Now: 10sec
<Stop> quit
