LAVAZZA LB 2800 - Machine Composition

5
2
2
1 Push button panel
2 Hot water dispensing push button
3 Boiler heating element indicator light working
4 Boiler pressure gauge
5 Hot water dispensing nozzle
6 Machine main switch
7 Adjustable foot
8 Coffee dispensing spout
9 Cappuccinatore
2
3
7
6
4
9
1
8
5
2
Manual code 10066574 / Rel. 0.00 / March 2009
Maintenance manual for technical assistance - LB 2800 - LB 2810
1.2.5. Machine composition
Note: if not expressly indicated in the text, the position numbers of the machine parts are referred to this figure.
