LAVAZZA LB 2800 - Internal Components

1.2.6. Internal components
1 Boiler
2 Electronic control unit
3 Volumetric dosing device
4 Boiler pressure gauge
5 Dispensing assembly
6 Drain tub
7 Internal motor pump
8 Cold water mixing tap
4
6
7
1
5
8
3
2
3
Manual code 10066574 / Rel. 0.00 / March 2009
Maintenance manual for technical assistance - LB 2800 - LB 2810
