aintenance manual for technical assistance - LB GUZZINI
Manual code 10083088 / Rel. 0.00 / January 2008
6
Warning
All the mechanical cable connections use anti-unthreading safety fastons. If the faston cover is present the
plastic should be pressed and pulled outwards, as shown in the figure.
Spanner 10 / 12 / 14 / 15 mm
Standard pliers
Long nose pliers
Screwdriver TORX T10
3 mm Allen key
PH1 Philips screwdriver
PH2 Philips screwdriver
Flat type screwdriver 0,8 x 4 x 80
7. TOOLS RECOMMENDED FOR MACHINE DISASSEMBLY
The following tools should be used to carry out the machine maintenance.
