2.5 Technical Specifications
Size (w x h x d) 280 x 380 x 480 mm
Weight approx. 9 kg
Machine housing material Thermoplastic material
Power Rating See the data plate
Supply Voltage See the data plate
Power cord length approx. 1,200 mm
Capacity Water tank 4 litres
Used capsule drawer
25 capsules
Capsule Type Lavazza BLUE
Control panel Front panel
A-weighted sound pressure level less than 70 dB
Pump pressure Max. 1.9 MPA (19.0 bar)
Operating conditions
Minimum temperature:
above 2°C
Maximum temperature:
less than 32°C
Maximum humidity:
less than 80%
Safety devices Boiler pressure safety valve
Safety thermostat
Subject to engineering and manufacturing changes due to technological improvements.
Machine compliant with EU Directive 2014/30/EU.
