LAVAZZA LB2317 - Main Parts

English
2
MAIN PARTS
1 Water tank lid
11
Cup holder (small cups)
2 Water tank
12
Cup holder (mugs)
3 Used capsule drawer
13
Drip tray
4 Power cord
14
Power button
5 Capsule loading tray
15
Chassis plug
6 Cup holder surface
16
USB port
7 Touch control panel
17
Ventilation fan
8 Hot water dispensing spout
18
Display
9 Moving coffee dispensing spout
19
Double espresso dispensing spout
10 Cappuccinatore cover
20
Cappuccinatore
