20. Networking Options
20.3.4 Stereo Tielines
"System -> Definition -> Parameter = TieLine Stereo"
This branch of the 'Tree Definition' supports 32 Stereo Tie Lines which can be used to dynamically assign
signals onto a MADI link between two compatible systems. This is useful if the number of inputs and outputs you
wish to share exceeds that of the available MADI links.
To use this feature you must configure the TCP Link under “System -> Definition -> Param = TCPLink”,
and Stereo Tie Line options for sending and receiving systems.
Start by selecting "System -> Definition" in 'Tree Definition' and the Audio tab. Scroll down to access the
"Parameter = TieLine Stereo" parameters:
TieLine Stereo – reference name for the element.
Enter the physical input used for the incoming Tie Line.
Enter the matrix address of the output from the external system.
Select this checkbox to enable the MNOPL protocol to use stereo tie lines with a Nova73.
