Rev: 05.25.21 Page 18 CCD-0004221
Troubleshooting
Relearn Sensors After Tire Rotation
If a tire rotation is performed on the vehicle, the user can relearn the sensors by utilizing the Learn All
Sensors mode.
Internal Sensors
When the battery voltage begins to approach 1.9V on a tire sensor, it is time to schedule a service
appointment to replace the sensor for that tire. If the battery is dead, the sensor assembly must be replaced.
The battery life is estimated to be three years.
NOTE: Use of tire sealant will cause damage to the internal sensor and may impact sensor readings.
Wrong Vehicle Chosen
In the event a wrong vehicle type is chosen, delete the incorrect vehicle from the Delete A Vehicle option in
the settings menu. See Delete A Vehicle section. Choose Add Another Vehicle to add a corrected vehicle. See
Add A Vehicle section.
No Power
If system is not working, check the in-line fuse to the dock to ensure the power dock has power.
Reset Repeater
1. Press and hold the Pair Mode button on the repeater (Fig. 47) for approximately 10 seconds.
2. Continue holding the button until there is one long red blink followed by four short red blinks.
3. Release button.
Reset LCD Handheld Display
1. Bend the end of a paper clip or use a similar tool that will fit into the reset hole in the LCD display (Fig. 48).
2. Insert the tool then press and hold for two seconds to reset the display.
Fig. 47
Fig. 48
Reset
Pair Mode Button
