Rev: 05.25.21 Page 8 CCD-0004221
Learn All Sensors
NOTE: A screen will be displayed for five seconds when accessing this mode. The screen will note: "Power
off all other displays connected to the repeater before learning sensors."
1. After entering the Learn All Sensors mode, hold the LCD display close to the sidewall in the area
opposite the valve stem of the tire to be paired (Fig. 12).
2. Press and hold the sync button on the LCD display (Fig. 4) to pair the sensor until the display beeps and
the red flashing circle turns green.
3. The display will feature a red dot representing the tire that is being paired, which will then turn green
when it is successfully paired (Figs. 13 and 14).
4. When pairing has been completed, the display will ask if another vehicle is to be added to the system
(Fig. 15). If pressing YES, pair the additional sensors in the proper sequence. If not, continue to
Configure All Thresholds.
NOTE: There are limits of three vehicles and 20 tires.
Fig. 12
Fig. 13
Fig. 14
Fig. 15
