Rev: 05.25.21 Page 7 CCD-0004221
Sensor Pairing Sequence
The pairing sequence for tires begins with the left front tire first, continuing from front to rear and then
beginning again at the right front and continuing to the rear tires. The spare tire is last.
With dual wheels on a vehicle, the outside tire on either side is paired first before the inside tire.
The illustration (Fig. 11) provides an example of the pairing sequence for tires on any vehicles.
Fig. 11
Rear
1
2
3
4
5
6
7
8
9
Spare
Front
