Jumpstart, or “Real hams don’t read manuals!”
Ok, but at least read this one section before you transmit:
Safety Warning: Never operate your AT-1000Pro with the cover removed; lethal RF voltages
may be present during operation. Never exceed the rated specifications
.
1. Connect your AT-1000Pro to a source of 11 – 15-volt DC power capable of supplying at
least 1 Amp. Press the Power button to turn on the tuner (Power LED will be on).
2. Connect your amplifier output to the AT-1000Pro input socket labeled “Transmitter” using
50-ohm coaxial cables. Connect the coax lead to your antenna to the AT-1000Pro output
socket labeled “Ant 1”.
3. Select Ant 1 (Ant 1 LED will be on). Select Auto mode to be off (Auto LED will be off).
4. Set your amplifier to “Standby” mode so it will NOT operate when you transmit.
5. Transmit a carrier from your exciter
of about 30 watts CW, FM or AM.
6. Momentarily press the “Tune” button on your AT-1000Pro. An automatic tuning cycle will
begin, then stop. Check the meter to ensure an SWR of 2 or less before using your amplifier.
7. Turn your amplifier on; you’re ready to transmit.
Specifications
• Microprocessor controlled Switched L tuning network
• Two position antenna switch with 2000 3-D memories for each position
• Adjustable threshold for Auto mode
• Lighted cross needle meters
• Continuous coverage 1.8 to 54 MHz
• Power rating HF (1.8 to 30 MHz):
o 1000 Watts Single Side Band
o 750 Watts CW
o 500 Watts Digital (RTTY, Packet, etc.)
• Power rating 6 meters: 250 Watts (any mode)
• Capacitor / Inductor fine tune controls
• Tuning time: 0.2 recall, 10 seconds average, 30 seconds max.
• Antenna impedance: 6 to 1000 Ohms (about 10:1 SWR, 3:1 on 6M)
• Dual meter scale 100/1000 watts
• Tuning power: 5 to 125 watts maximum
• Relay protection software prevents tuning:
o Greater than 125 watts in any load
o Greater than 75 watts into a 3:1 SWR load
• Soft touch buttons
• Includes 6 foot power cable, Icom and Yaesu interface, coax jumper (300 watt limit)
• Power requirements: 11 to 15 volts DC @ 1 Amp (user supplies power source)
• Enclosure sizes: 9.5W x 13D x 3.5H inches
•
Weight: 5.2pounds
