Grounding: Be sure to use a good ground whenever possible. Grounding may help if you have
lockup problems or poor tuning. Grounding may also help in cases where there is stray RF. Stray
RF can usually be determined by the RF power setting on your radio. If the power is reduced and
the problem goes away, it’s probably stray RF.
Reset the processor: Under some conditions, the tuner’s processor may stop functioning. In this
case, remove the DC power plug from the rear panel, wait five seconds, then re-insert the DC
power plug.
Chokes: In some circumstances, the interface or DC power cables to the tuner may need to have
RF chokes applied. The most common type is the snap-on unit available at many local electronic
stores. Chokes are useful to remove RF interference from interface or DC power cables.
Care and Maintenance
Your Z-100 tuner is essentially maintenance-free; just be sure to observe the power limits
discussed in this manual. The outer case may be cleaned as needed with a soft cloth slightly
dampened in household cleaning solution. As with any modern electronic device, your Z-100 can
be damaged by temperature extremes, water, impact or static discharge. LDG strongly
recommends that you use a good quality, properly installed lightning arrestor in the antenna lead.
Technical Support
We are happy to help you with your product. For detailed tech support, submit our Tech Support
form on our web site under Support/Manuals, then Tech Support. You can find us at
www.ldgelectronics.com
.
Warranty and Service
Your product is warranted against defects in parts or workmanship for two years from purchase.
The warranty does not cover damage due to abuse or exceeding specifications. This warranty
applies to the original purchaser only; it is not transferable. A copy of the receipt showing the
purchaser’s name and the date of purchase must accompany units returned for warranty service.
All returns must be shipped to us pre-paid; we will not accept units with postage due. Please fill
out and print the return form from our web site under Support/Manual, then Tech Support-
Warranty.
If you need to return your unit to us for service, package it carefully, keeping in mind that we will
re-use your packaging to return the unit to you. Include a full description of the problem, along
with your name, address and a phone number or e-mail address on the web form. Repairs average
about 3 to 6 weeks.
We will be glad to service your unit after the warranty period has ended. We will notify you of
repair charges by phone or e-mail, and bill you after repairs are completed.
12
INRADIO
ABEL & PRO-FIT Centrum Radiokomunikacji
tel. fax:
e-mail:
internet:
ul. Puszkina 80 92-516 £ódŸ Poland
(+42) 649 28 28 (+42) 677 04 71
biuro@inRADIO.pl
www.inRADIO.pl
Autoryzowany Przedstawiciel LGD w Polsce:

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the LDG Z-100 and is the answer not in the manual?

LDG Z-100 Specifications

General IconGeneral
Frequency Coverage1.8 to 54 MHz
Memories2000 memories
Latching RelaysYes
ConnectorsSO-239
Tuning SpeedFast
Power SupplyExternal DC
Weight1.5 pounds
Impedance Range6 to 1000 ohms
Control InterfaceNone (manual operation)
