and sets those parameters in a fraction of a second, much faster than a full tuning cycle. 3-D
memory is an exclusive LDG technology, available only in LDG tuners.
When you tune using Semi mode, you can select between a Memory tune and a Full tune. If you
select Memory tune and there is no appropriate memory data, the tuner will automatically begin a
full tuning cycle. Tuning parameters are stored in EEPROM memory, and are retained
indefinitely, even if power is removed. In Auto mode, Memory tune is used.
Using your Z-11Pro with the DTS-4 Intelligent Antenna Switch
3-D memories make switching among various antennas a breeze. Using LDG's DTS-4 Intelligent
Desktop Antenna Switch, you can instantly connect up to four separate antennas with the press of
a button. Your Z-11Pro will search it's 3-D memory bank for stored settings for each antenna and
for the present frequency, and reset to them in less than 0.1 seconds. Working together, your Z-
11Pro and DTS-4 Intelligent Antenna Switch makes switching and matching up to four antennas
automatic and virtually instantaneous.
The small size of the DTS-4R remote control for the DTS-4 Intelligent Antenna Switch makes it
especially appropriate for use with the compact Z-11Pro. The information on the next page shows
how these two groundbreaking LDG products can be used together.
12
Z-11Pro
Tuner
DTS-4
Intelligent
Switch
Transceiver
Yagi
Quad
Dipole
Vertical
Z-11Pro
Tuner
DTS-4
Intelligent
Switch
Transceiver
Yagi
Quad
Dipole
Vertical
You can connect up to four antennas to the DTS-4 Intelligen
Antenna Switch, and then connect to your transceiver via the
Z-11Pro tuner. Instant switching, automatic safety
grounding, and 3-D memory tuning make changing antennas
nearly instantaneous.
The Z-11Pro with the DTS-4R remote control, connected to
the DTS-4 Intelligent Antenna Switch, ready to rock and
roll. You can instantly switch between any of four antennas,
and the Z-11Pro will recall separate saved tuner settings fo
each antenna in less than 0.1 seconds.
