H2-506 Vector Easy Servo Drive User Manual Version 1.0
Leadshine Technology Co., Ltd
11/F, Block A3, iPark, No.1001 Xueyuan Blvd. Shenzhen, China Tel: 1-949-608-7270 Fax: 1-949-608-7298
Web: www.leadshine.com Email: tech@leadshine.com
3
PE
I
4
A+
O
Motor phase A+
5
A-
O
Motor phase A-
6
B+
O
Motor phase B+
7
B-
O
Motor phase B+
3.4 Connector Pin-Out
CN1 – Control Signal Connector
CN2 – Feedback Signal Connector
CN3 – RS232 & RS485 Connector
Power Supply Connector
6 FG
7 EZ+
8 EZ-
9 NC
10 NC
1 EA+
2 EB+
3 GND
4 NC
5 NC
11 EA-
12 EB-
13 +5V
14 NC
15 NC
1 GND
2 TxD
3 +5V
4 RxD
5 NC
6 NC
