Leckey Squiggles Stander - Inserting Attachment Bolt into Sandals; Attaching and Adjusting the Foot Sandals

Squiggles Stander - User Manual p15
9.9 INSERTING
ATTACHMENT BOLT
INTO THE SANDALS
Insert the required attachment bolt
along with the retention plate . Place
a rubber lid
C
on, both, the top and
bottom of the sandal. Fasten using the
four screws provided. To remove or
replace the attachment bolt, reverse this
process.
C
9.10 ATTACHING
THE SANDALS
Place the sandal so that the attachment
bolt goes through the slot in the
footplate. To secure, on the underside of
the footplate place the rubber washer
, followed by the metal washer and
then the knob
C
onto the attachment
bolt. To position the sandals simply
loosen the knob
C
under the footplate,
select the position you require and
re-fasten the knob.
C
