E2]
3
4
1
[E3]
1
CPU Board Replaceable Parts
Item
IWATSU Part Number
Quantity
Description
1 MKB130062
18.0
Screw
M3x6
2
21302-5610
1.0
CPU BOARD ASSY
3
KBA784421
1.0
TOP FRAME L
4
KBA784511
1.0
TOP FRAME R
Mechanical Part & Removal
7-9
122
124
