3-4 Specifications
3.10 Color Waveform Display
Type: VGA Color 8.4-inch flat-panel TFT-LCD
Resolution: 640 x 480 resolution
Screen Saver: Display blanks after 10 minutes (when screen saver is enabled)
Real Time Clock: Date, hours, minutes, and seconds displayed with waveform
Number of Traces: Display a maximum of eight traces. Simultaneously display channel,
zoom, memory, and math traces
Grid Styles: Single, Dual, Quad, Octal, XY, Single+XY, Dual+XY; Full Screen gives
enlarged view of each style
Intensity Controls: Separate intensity control for grids and waveforms
Waveform Styles: Sample dots joined or dots only — regular or bold sample point
highlighting
Trace Overlap Display: Select opaque or transparent mode with automatic waveform
overlap management
3.11 Analog Persistence Display
Analog Persistence and Color Graded Persistence: Variable saturation levels; stores
each trace’s persistence data in memory
Trace Selection: Activate Analog Persistence on a selected trace, top 2 traces, or all
traces
Persistence Aging Time: Select from 500 ms to infinite
Trace Display: Opaque or transparent overlap
Sweeps Displayed: All accumulated or all accumulated with last trace highlighted.
3.12 Zoom Expansion Traces
Style: Display up to four zoom traces
Vertical Zoom: Up to 5x expansion, 50x with averaging
Horizontal Zoom: Expand to 2 pts/div, magnify to 50 000x
Autoscroll: Automatically scan and display any zoom or math trace
3.13 Rapid Signal Processing
Processor: Power PC
Processing Memory: Up to 128 Mbytes
Realtime Clock: Dates, hours, minutes, seconds, and time stamp trigger time to 1ns
resolution.
3.14 Internal waveform Memory
