Leeson 174621 - About These Instructions

This documentation applies to the SM2 Vector frequency inverter, and contains important technical
data and describes installation, operation, and commissioning.
These instructions are only valid for SM2 Vector frequency inverters with software rev 20
(see drive nameplate).
Please read the instructions before commissioning.
CA
B D
Type:
174621.00
Id-No: 00000000
INPUT:
3~ (3/PE)
400/480 V
2.9/2.5 A
50-60 HZ
OUTPUT:
3~ (3/PE)
0 - 400/460 V
2.4/2.1 A
0.75 KW/1HP
0 - 500 HZ
For detailed information
refer to instruction
Manual: SV06
Made in USA
Inverter
SM2 Vector
V0115
• 1 SM2 Vector inverter
LEESON does
.
LEESON representative.
2
About these instructions
A
Certifications
C
Input Ratings
B
Type
D
Output Ratings
Scope of delivery Important
with EPM installed
(see Section 4.4)
• 1 Operating Instructions
After receipt of the delivery, check immediately whether the items
delivered match the accompanying papers.
not accept any liability for deficiencies claimed subsequently.
Claim
• visible transport damage immediately to the forwarder.
• visible deficiencies / incompleteness immediately to your
