The table below shows the possible SPEED REFERENCE SOURCE indications for the auxiliary status
display:
SPEED REFERENCE TABLE
DISPLAY DESCRIPTION
KEY KEYPAD - UP and DOWN arrow keys
VDC 0 - 10 VDC analog input at TB-5A
IDC 4 - 20 mA analog input at TB-5B
SP#1 PRESET SPEED #1
SP#2 PRESET SPEED #2
SP#3 PRESET SPEED #3
SP#4 PRESET SPEED #4
JOG JOG SPEED
(In JOG mode, JOG SPEED - PRESET SPEED #2)
MOP "MOTOR OPERATED POT" –
Change speed using contact closures
at TB-13A (DEC FREQ) and
TB-13B (DEC FREQ)
