The following table shows the possible DRIVE STATUS indications that can appear on the drive display:
DRIVE STATUS TABLE
DISPLAY DESCRIPTION
STOP Drive is in STOP mode - No output to the motor.
RUN Drive is in RUN mode and is within
+
/- 3 Hz of the speed setpoint.
FAULT Drive has shut down due to a FAULT condition. If the fault condition has
passed, pressing the STOP key will clear the fault and return the drive to the
STOP mode.
LOCK Drive is in FAULT LOCKOUT due to five unsuccessful restart attempts.
BRAKE DC BRAKE is energized.
LIMIT Drive is in CURRENT LIMIT due to an overloaded motor, or ACCEL is too
fast.
FDEC Drive is in DECEL FREEZE because DECEL is too fast.
