Technical data sheet: S000074405EN-2 Updated: 10/02/2016 Created: 18/01/2013
Catalogue Number(s): 0 488 04
PIR switch sensor
3. DIMENSIONS
Without protective cover
4. CONNECTION
Number of terminals: 6
Type of terminals: automatic
Terminal capacity: 2 x 2.5 mm
2
Stripping length: 8 mm
4.1 Wiring with auxiliary control:
100 m max.
With protective cover
8.5 A
8.5 A
71 73
Ø: 105
66 72
62
Ø: 105
2 A
2 A
U≤30V=
Ext. supply
L1
L1
PB
230
110
DC
VAC
Wiring
