3/8
CONTENTS
Technical data sheet: S000074405EN-2 Updated: 10/02/2016 Created: 18/01/2013
Catalogue Number(s): 0 488 04
PIR switch sensor
4.CONNECTION (continued)
4.2 Wiring for a single load connected in parallel
2 A
SN
SN
LN
S2
S2
L2
S1
S1
L1
PB
8.5 A
100 m
8.5 A 8.5 A
2 A
L
PB
8.5 A
100 m
4.3 Wiring for several loads connected in parallel
