111
DMX
3
Termination
support must
be made
of isolating
material and
sized according
to the bars in
order to avoid
performances
during
short circuit
conditions.
ø11
130130130
70
15
11mm
11mm
"X" max (mm)
"X" max (mm)
L3
L2
L1
N
DMX
3
4000.
Icc (kA) ≤ 42 ≤ 50 ≤ 65 ≤ 100
“X” max (mm) 350 300 250 150
