112
DMX
3
Termination
support must
be made
of isolating
material and
sized according
to the bars in
order to avoid
performances
during
short circuit
conditions.
11mm
11mm
ø11
130130130130130130130
70
L3L3L2L2L1L1
NN
15
"X" max (mm)
"X" max (mm)
DMX
3
6300.
Icc (kA) ≤ 42 ≤ 50 ≤ 65 ≤ 100
“X” max (mm) 350 300 250 150
