5-3. Audible alarm
Battery mode Sounds every 4 seconds
Low battery Sounds every second
Overload Sounds twice every second
Fault Sounds continuously
Bypass mode Sounds every 10 seconds
11
5-4. LCD display wordings index
Abbreviation
ENA
DIS
ESC
HLS
LLS
BAT
CF
TP
CH
FU
EE
Display content Meaning
Enable
Disable
Escape
High loss
Low loss
Battery
Converter
Temperature
Charger
Bypass frequency unstable
EEPROM error
EnA
dIS
ESC
HLS
LLS
CF
CH
FU
EE
5-5. UPS setting
12
Interface Setting
01: Output voltage setting
02: Frequency converter enable/disable
03: Output frequency setting
0 1
230
OUTPUT
Vac
02
EnACF
03
5OOCF
Hz
OUTPUT
Parameter 2 & 3: Output frequency setting. You
may set the initial frequency on battery mode:
BAT 50: presents output frequency is 50Hz.
BAT 60: presents output frequency is 60 Hz. If
converter mode is enabled, you may choose the
following output frequency:
CF 50: presents output frequency is 50 Hz.
CF 60: presents output frequency is 60 Hz.
Parameter 3: Output voltage
For 200/208/220/230/240 Vac models, you may
choose the following output voltage:
200: Presents output voltage is 200 Vac
208: Presents output voltage is 208 Vac
220: Presents output voltage is 220 Vac
230: Presents output voltage is 230 Vac (Default)
240: Presents output voltage is 240 Vac
Parameter 2 & 3: Enable or disable converter
mode. You may choose the following two options:
CF ENA: Converter mode enable
CF DIS: Converter mode disable (Default)
There are three parameters to set up the UPS.
Parameter 1: For program alternatives. Refer to table.
Parameter 2 and Parameter 3 are setting options or values for
each program.
88
888 888
Parameter 1
Parameter 2 Parameter 3
