24
5.4.1 UPS Status
UPS Info
Model Equipment model (TRIMOD)
SYNC. address Synchronisation address of the command board
Number of CM Number of command boards recognised
Max VA Maximum apparent power[kVA]
Max W Maximum active power [kW]
Max Ichg Maximum current available to charge the batteries [A]
SW Ver. Firmware version of the command board
PM SW Ver. Firmware version of the power modules
Boot Ver. Bootloader version in the command board
S/N UPS serial number
UPS Cfg
OUT Single Phase/ Three Phases 120° / Three Phases indep.
IN Single Phase / Three Phases / inv.3 phases / Undefined (_ _ _)
BYP Single Phase / Three Phases / inv.3 phases / Undefined (_ _ _)
X/Y - X/Y - X/Y
X Power modules for each phase managed by the command board
Y Power modules for each phase managed by the UPS
Number BCM Number of Battery Charger Modules recognised
Installed KB Number of KB installed
Batt. Cap. Capacity of the batteries installed [Ah]
Batt.N per KB Number of batteries in series available in one KB
Measures Output X
Power Output active power on phase X [W]
Appar. Power Output apparent power on phase X [VA]
Vrms Output effective voltage on phase X [V rms]
Vrms ph-ph Output effective line voltage [V rms]
Irms Output effective current on phase X [A rms]
Peak Current Output peak current of phase X [A]
Frequency Pure sine output voltage frequency on phase X [Hz]
I Crest factor Crest factor for phase X
Power fact. Power factor of the load connected to the UPS on phase X
Max W Maximum active power on phase X [W]
Power
Output active power on phase X, expressed as a percentage in
relation to the maximum active power available on phase X [%]
Max VA Maximum apparent power on phase X [VA]
Appar. Power
Output apparent power on phase X, expressed as a percentage in
relation to the maximum apparent power available on phase X [%]
INDICATION
To change the value of X and therefore vary the phase from which the data is read, press the ENTER key after entering the
submenu.
