5.4.3 Power Modules
PM Status
PM Info X
Mod. Model of power module X
SW Ver Version of the firmware inside power module X
HW Ver Hardware version of power module X
S/N Serial number of power module X
Max VA Maximum apparent power available for power module X [VA]
Max W Maximum active power available for power module X [W]
Max Ichg Maximum current available from the battery charger of power module X [A]
PM
Measures
Input X
Power Active power absorbed by power module X [W]
Appar.Power Apparent power absorbed by power module X [VA]
Vrms Effective input voltage of power module X [V rms]
Vrms bypass
Effective input voltage for power module X of the bypass
line [V rms]
Vrms ph-ph Effective input line voltage of power module X [V rms]
Irms
Effective current absorbed from the mains by the power
module X [A rms]
Peak Current Input peak current of power module X [A]
Frequency
Pure sine input frequency voltage of power module X for the
bypass line [Hz]
I Crest factor Crest factor applied by power module X to the mains
Power Fact. Power factor applied by power module X to the mains
Output X
Power Active power supplied by power module X [W]
Appar. Power Apparent power supplied by power module X [VA]
Vrms Effective output voltage of power module X [V rms]
Vrms ph-ph Effective output line voltage of power module X [V rms]
Irms Effective output current supplied by power module X [A rms]
Peak Current Output peak current of power module X [A]
Frequency Pure sine output voltage frequency of power module X [Hz]
I Crest factor Crest factor of the output current of power module X
Power Fact. Output power factor for power module X
Max W Maximum active power available from power module X [W]
Power
Active power supplied by power module X, expressed as
a percentage in relation to the maximum active power
available from power module X [%]
Max VA Maximum apparent power available from power module X [VA]
Appar. Power
Apparent power supplied by power module X, expressed as
a percentage in relation to the maximum apparent power
available from power module X [%]
(continues)
5. Control panel
