32
5.4.4 Events
Events
Log View
All This displays all the events
Critical
This displays the events that have generated
critical alarms
Warning
This displays the events that have generated non-
critical alarms
Info
This displays the events that have generated
simple warnings
5.4.5 Tools
Battery
Battery Test Automatic
This performs a test on the batteries to check their
status and performance
Batt. Calibration
This calibrates the batteries, finding the discharge curve.
In order for the UPS to provide precise information regarding the charge
status, it is necessary to perform the calibration in the following cases:
- after installation and before the first start-up;
- in case the batteries are replaced;
- every six months after the first year of the UPS's life.
Battery cycle
This carries out a battery test and their equalization to check the status,
the performance and to maximise the life of the batteries.
Signalling Test (*)
This carries out the signalling test of the status indicator signal (green, orange and red) and of
the acoustic signalling.
LCD Display Test
(*)
This performs the test of the alphanumeric display. When the ENTER key is pressed, all the avai-
lable characters are displayed.
(*) Only available in “Service Mode”
Assistance
Display
Identifier
This displays the code to communicate to the technical support service.
Use code Insert the code provided by the Technical Support Service.
CM errors recovery
This clears the memory of the errors detected by the command board.
It works only with resettable errors.
5.4.6 Log Out
It is possible to set a password to prevent non-authorised personnel to modify the configuration of the UPS.
By choosing a password, it is necessary to enter a private session to modify the UPS settings. At the end of the operations
use the "Log Out" menu to leave the private session.
If the password has been forgotten, it is necessary to contact the LEGRAND Technical Support Service.
5. Control panel
