Leica Nova MS60 - Scanning

MS60/TS60, Technical Data
71
7.6 Scanning
Availability Available for MS60 R2000 and on CS when connected to MS60 R2000.
Range The following ranges refer to optimal measurement conditions (object in shade, sky
overcast, static target object).
Accuracy Range noise* (1 sigma; Kodak Grey Card (Albedo 90%)):
Object in shade, sky overcast. Beam interruptions, severe heat shimmer and moving
objects within the beam path can result in deviations of the specified range noise and
accuracy.
The absolute position accuracy of a modelled surface is similar to an RL single meas-
urement:
Mode Kodak Grey Card (Albedo 90%) Range, up to
[m] [ft]
1000 Hz White side, 90% Albedo 300 980
250 Hz 400 1310
62 Hz 500 1640
>1 Hz 1000 3280
Shortest measuring distance: 1.5 m
Distance 1000 Hz 250 Hz 62 Hz 1Hz
10 m 0.6 mm 0.5 mm 0.4 mm 0.4 mm
25 m 0.8 mm 0.6 mm 0.5 mm 0.5 mm
50 m 1.0 mm 0.8 mm 0.6 mm 0.6 mm
100 m 2.0 mm 1.0 mm 0.8 mm 0.8 mm
200 m 6.0 mm 3.0 mm 2.0 mm 1.8 mm
* Range noise describes the standard deviation of the scan points residuals to the
modelled surface:
• Plane surface target
• Perpendicular orientation of the plane target to the measurement direction
• Modelled plane best fitted into the point cloud
Standard measuring std. dev. ISO 17123-4
0 m - 500 m 2 mm + 2 ppm
>500 m 4 mm + 2 ppm
