30
Technical Data
Sprinter 150/150M/250M - 1.0.0en
EN
DE
FR
ES
NO
SV
FI
DA
IT
PT
NL
Internal Memory Storage* Capacity: up to 1000 points.
Data Transfer* Program: To DataLoader via USB, to Leica Geo Office and HyperTerminal via RS232 on PC, using a
Windows® application
Power Supply • Sprinter 150: internal battery
• Sprinter 150M/250M: internal battery and external via RS232 port.
Battery Power Battery internal: AA dry cells 4 x 1.5 V; powered via RS232 port:
Nominal voltage 12 V ,
voltage range 4 - xx V ,
GEV71 power cable to a 12 V car battery; current rating max. 300 mA.
LCD • Type: Monochrome display with backlight capability
• Dimensions: 128 x 104 pixels
Telescope • Magnification (Optical): 24 x
• Free objective diameter: 36 mm
• Clear Objective Aperture: 2 °
• Multiplication constant: 100
• Addition constant: 0
Hz Circle Circle Engraving:
Plastic horizontal circle of 360° (400 gon). Graduation and numerals scale resolution at 1°(upper scale)
and at 50 gon intervals (lower scale)
Side Drive Movement & Play in side drive: Continuous horizontal dual drive
System • MMI capability
• Measuring / applications
• Keyboard: 5 rubber keys
Temperature Range • Operating Temperature: -10°C to +50°C
• Storage Temperature: -40°C to +70°C
