ATTACHING THE LEIGH E-BUSH TO THE ROUTER
70
Appendix I D4R Pro User Guide
1
ROUTER
MAKER
2
ROUTER
MODEL
3
ROUTER
ADAPTOR
4
7/16" OD
BUSHING
◆
5
5/8" OD
BUSHING ▲
AEG
OFE 710 in plunge base Not Required
e7 or 711C 716C
OFSE 2000 703
e7 or 711C 716C
RT1350E 706R
e7 or 711C 716C
BLACK & DECKER
All Professional, HD1250, RP400K, 7614 Not Required e7 or 711C 716C
6200 720673-00 e7 or 711C 716C
SR100, 7AEE, KW780 series, KW800, KW850 710 e7 or 711C 716C
BOSCH
90085, 90088, 90098, 90140, 90150, 90300, 90303, 90305, 91264 Aftermarket base plate required e7 or 711C 716C
1600, 1601, 1602, 1603, 1604, 1606, B1350 RA1110 required e7 or 711C 716C
North American ROUTERS PRODUCED AFTER mid-2010: 1613EVS, 1613AEVS, 1617,
1617EVS, 1618, 1618EVS, 1619EVS, MR23EVS, MRC23EVS, MRF23EVS, MRP23EVS
RA1100 & RA1126 required
Sold only as Set RA1129
(Set includes RA1100 and RA1126)
e7 or 711C 716C
North American ROUTERS PRODUCED BEFORE mid-2010 and others available
worldwide that include the RA1126 adaptor: 1613(EVS)(AEVS), 1614(EVS), 1617EVS,
1618EVS, 1619EVS, B1450, GOF900(CE)(ACE), GOF1200, GOF1250(CE)(LCE),
GOF1300(CE)(ACE), GOF1600CE, GOF2000CE, GMF1400, GMF1600CE, POF800ACE,
POF1100AE, POF1200AE, POF1400ACE
RA1100 required
Sold only as Set RA1129
(Set includes RA1100 and RA1126)
e7 or 711C 716C
1611, 1611EVS, 1615, 1615EVS, B1550, GOF1600, GOF1700ACE 702 e7 or 711C 716C
CRAFTSMAN
(SEARS)
All non-plunge models Aftermarket base plate required e7 or 711C 716C
135275070 Plunge See Skil 1823 or 1835
Other plunge models 702 e7 or 711C 716C
MD11 Plunge & Fixed Base. MD9.5 Fixed Base Not Required e7 or 711C 716C
DEWALT
DW610, DW616, DW618 Not Required e7 or 711C 716C
DW613, DW615(UK) 710 e7 or 711C 716C
DW614, DW615, DW621, DW624, DW625, DW626 N. America Only, Supplied w/router e7 or 711C 716C
DW621K, DW622 and DW626 outside N. America 706R e7 or 711C 716C
DW625 Type 1,2,3,5 outside N. America 702 e7 or 711C 716C
DW624 & DW625 Type 4 outside N.America, DW625EK 702R e7 or 711C 716C
ELU
OF15, OF15E, OF97, OF97E 706R e7 or 711C 716C
MOF68, MOF69, MOF96, MOF96E 710 e7 or 711C 716C
MOF131, MOF177 Type 1,2, & 3 702 e7 or 711C 716C
MOF177 Type 4, MOF177EK 702R e7 or 711C 716C
2720, 2721, 3328 Not Required e7 or 711C 716C
3303, 3304 EO9600 or 761 270-00 e7 or 711C 716C
3337, 3338, 3339 702 e7 or 711C 716C
FEIN RT1800 Supplied w/router e7 or 711C 716C
FESTOOL
OF1E , OF2E, OF650, OF900E ,OF1000, OF1010E 704R e7 or 711C 716C
OF2000, OF2000E 705R e7 or 711C 716C
OF1400 and OF2200 North America Only Supplied w/router e7 or 711C 716C
OF1400 Outside North America 493566 e7 or 711C 716C
OF2200 Outside North America
494627 O-Ring may be required
to keep bushing centered
e7 or 711C 716C
FREUD FT1700(2), FT2000, FT2200, FT3000 721 e7 or 711C 716C
HITACHI
TR8, TR12, FM8, M8, M12 Series 325211 OR 703 e7 or 711C 716C
M12VC, KM12SC, KM12VC Not Required e7 or 711C 716C
M12SA2, M12V2 325224 e7 or 711C 716C
MAFELL LO65E 702 ■ e7 or 711C 716C
MAKITA
M363, MRP090, RP1800(F), RP1801(F), RP2300(FC), RP2301(FC), 3612C Europe Qk Fit Base
721 e7 or 711C 716C
3600, 3606, 3608, 3612, 3612B, 3612BR, 3612C N. America, 3620, 3621, RP0900,
RP900K
703 e7 or 711C 716C
3601B 321 493-1 e7 or 711C 716C
RP0910, RP1110C 706R e7 or 711C 716C
RF1100, RF1101, RD1100, RD1101, RP1101 Not Required e7 or 711C 716C
MASTERCRAFT
Please contact Leigh for assistance
METABO OF1612, OFE1812 (for all others, please contact Leigh for assistance) 704R e7 or 711C 716C
MILWAUKEE
5615, 5616, 5619 49-54-1040 (replacement base) e7 or 711C 716C
5625 49-54-1026 (replacement base) e7 or 711C 716C
5670 Not Required e7 or 711C 716C
PERLES OF808 Series, OFE6990 710 e7 or 711C 716C
PORTER-CABLE
(ROCKWELL)
Most Not Required or Supplied w/router e7 or 711C 716C
8902
Porter-Cable Sub-Base 42186 e7 or 711C 716C
RIDGID R2930 (for all others, please contact Leigh for assistance) 704R e7 or 711C 716C
RYOBI
R30, R50, R150, R151, RE155, R500, R501, R502 703 e7 or 711C 716C
R600, R601, RE600, RE601 702 e7 or 711C 716C
R160, R161, R162, R163K, R165, R170,
R175, RE175, R180, R180PL, R181, R185, ERT1150
706R e7 or 711C 716C
SKIL
1823 or 1835 91803 e7 or 711C 716C
SK1810, 1815, 1820, 1825 RAS140 e7 or 711C 716C
All others Aftermarket base plate required e7 or 711C 716C
TREND T3, T4, T5, T9, T10, T11– UniBase required 710 e7 or 711C 716C
TRITON
TRC001 TGA006 or 704R e7 or 711C 716C
JOF001, MOF001, TRA001
Accessory Kit (includes adaptor)
TGA001 or TGA150
e7 or 711C 716C
WEGOMA OF850 Series 710 e7 or 711C 716C
Template Guide Bushing and Adaptor Selection
Leigh dovetail jigs require a router fi tted with a guide bushing. An adaptor may be required to fi t the bushing to the
router.
See www.leighjigs.com for the complete list of routers.
DIRECTIONS
A. Locate name of router maker in
Column 1.
B. Locate router model in Column
2. If your router is not listed visit
leighjigs.com for a complete, up-
to-date list of routers.
C. Locate adaptor required for your
router in Column 3.
• Order Leigh adaptors (part no’s in
red) in Column 3 from Leigh.
• Order Bosch adaptors RA1100 and
RA1126 in Column 3 from Leigh or
your Bosch dealer.
• Order all other adaptors in
Column 3 from the router
manufacturer’s dealer.
Note: Adaptor mounting screws are
included with router.
■
MAFELL – Rework adaptor
slightly.
D. Guide bushings in Columns 4 and
5 fi t all adaptors listed and may be
ordered if required. Note:
◆ The
e7 elliptical guide bushing
(7/16" [11,1mm]) is supplied
with all Leigh D-series dovetail
jigs for routing dovetails and
box joints. Order only if you
require a replacement. The
711C/711TP* guide bushing
(7/16" [11,1mm]) can also
be used, but only for routing
dovetails.
▲
An optional 5/8"[15,9mm] 716C
or 716TP* guide bushing is used
with 1/2"[12,7mm] shank router
bits on D4R Pro, D4R, D4, D3,
D1258R, D1258, jigs. Order only
if using 1/2"[12,7mm] shanks.
All 8mm shank bits work with the
e7-Bush supplied with your Leigh jig,
or with any
7/16
"OD[11,1mm] guide
bushing that has a min. barrel length
of 1/4"[6,35mm]. No other guide
bushing sizes can be used.
Note:
*The 711C has replaced the 711TP
guide bushing. Both are
7/16
"OD
[11,1mm].
*The 716C has replaced the
716TP guide bushing. Both are
5/8"OD [15,9mm].
