BIT SELECTION
76
Appendix II D4R Pro User Guide
Leigh Half-Blind Dovetail Bits









80
-
8
Tail board
Drawer Side
Min Thickness
1/4"[6,5mm]
Pin board
Flush Drawer Front
Min Thickness
HB Variable: 7/8"[22mm]
HB Single Pass:
35/64"[14mm]
Pin board
Flush Drawer Front
Min Thickness
HB Variable: 3/4"[19mm]
HB Single Pass:
31/64"[12,3mm]
Pin board
Flush Drawer Front
Min Thickness
HB Variable: 5/8"[15,9mm]
HB Single Pass:
27/64"[10,7mm]
Pin board
Rabbeted Drawer Front
Min Rabbet Depth
13/16"[20,5mm]









101-8
Tail board
Drawer Side
Min Thickness
1/4"[6,5mm]
Pin board
Rabbeted Drawer Front
Min Rabbet Depth
11/16"[17,5mm]
Tail board
Drawer Side
Min Thickness
1/4"[6,5mm]









112-8
Pin board
Rabbeted Drawer Front
Min Rabbet Depth
9/16"[14,5mm]
Numbers in brackets are millimeters * Bits 80-8, 120-8, and 140-8 come standard with the Leigh D4R Pro
Bits
A
Overall Diameter
B
Working Depth
C
Shank Diameters
D
Shank Length
E
Overall Length
F
Angle
Guidebush
Diameter
HB Variable HB Single Pass
No. 80-8*
1/2" [12,7] ~3/4" [19] ~27/64" [11] 8mm (or 1/4") 1-3/4" [44,0] 2-9/16" [65,0] 8˚ e7 or 7/16"[11,1]
Bits
A
Overall Diameter
B
Working Depth
C
Shank Diameters
D
Shank Length
E
Overall Length
F
Angle
Guidebush
Diameter
HB Variable HB Single Pass
No. 101-8
1/2" [12,7]
~5/8" [15,9]
~23/64" [9] 8mm (or 1/4") 1-3/4" [44,0] 2-3/8" [60,0] 10˚ e7 or 7/16"[11,1]
Bits
A
Overall Diameter
B
Working Depth
C
Shank Diameters
D
Shank Length
E
Overall Length
F
Angle
Guidebush
Diameter
HB Variable HB Single Pass
No. 112-8
1/2" [12,7] ~1/2" [12,7] ~19/64" [7,5] 8mm (or 1/4") 1-3/4" [44,0] 2-21/64" [59,0] 12˚ e7 or 7/16"[11,1]
Included
with
D4R Pro
