RTJ400 User Guide
Chapter 10
Box Joint Procedures - 3/8"
NOTE: See ⅜" Half-Blind Box Joints section on the next page.
10-20 Rout the sockets making sure to contact both sides of
each opening with the guide bushing. Flip the board and rout
the other end. Repeat the procedure for socket board 2. All four
boards are now complete and ready for assembly.
10-21
Flushness If the joint is over flush, lower the bit to suit.
If the joint is under flush, raise the bit to suit. Rout a fresh test
joint until fit and flushness are perfect before routing the actual
workpieces.
■
OVER FLUSH UNDER FLUSH
