Leitner Libelle 2020 - Frame Folding and Reflector Checks; Folding and Straightening the Frame

Foldingtheframe(foldingmodelsonly):Releasingthequick‐releasefoldingmechanismattheframe
C)Movethequick‐release
levertoyourleft.
A)quickreleaseleverin
firmlyclosedposition
B)openthequick‐release
lever.
D)Push thequick‐releaseboltUP
andatsametimewiggleleftand
rightuntilyouheara“CLICK”.Then
foldframe.Puttingthumbontopof
frameandindexfingerunderneath
boltmaymakeunlockingeasier.
Foldedbike,viewfromfront
Handle‐stemfoldedto
rightsideoffront‐
wheel
2)Tostraightentheframe,
carefullymovethefrontpartof
theframeinthedirectionofthe
arrowshown.
1)Userto
standonthis
sideto
straighten
foldedframe.
Hinge
of
folding
frame
3)Thefoldingframeisnowstraight.Follow
theguidebelowtolocktheframesafely
beforeriding.Thehandle‐barcanbe
straightenedlater.Firstlocktheframe.
Foldingmechanism
5)Closetheframecompletely,
thenpushquickreleasebolt
down.NowitshouldNOT be
possibletofoldtheframein
thisposition.
7)Closequick‐release
leveruntilitissafely
securedandwon’tget
loosewhileriding.If
necessarytightennut
beforeclosinglever.
Refertoquick‐release
sectionofthismanual.
6)Movequick‐releasebolt
towardsfrontofbikeand
insertintoslotatfrontpart
offrame.
4)Toclosetheframefirstpush
thequick‐releaseboltUP .You
mayhavetowiggleleftandright
atthesametimewhilepushing
UPtoensuretheboltisallthe
wayUP.
Nut
Straighteningtheframe
Bolt
WARNING!Pinching
hazard.Stayclearof
areaaroundfolding
hinge.
The folding stem should fold to the right side of the bike. The handle‐bar should be approximately parallel to the bike
frame when fully folded. Fold carefully. Take care not to pinch body parts and not to damage the bike during the folding
procedure. Hold on to moving parts and do not drop parts as they may smash into the bike. Make sure to leave enough
slack for all wires to avoid damaging wires while folding. During transport, for example inside car, secure bike safely to
prevent it from moving. Use padding material like rags or blankets to protect bike parts which are touching from damage
during transport.
17
Reflectors
• Every 3 months check that all reflectors are clean, installed securely and not covered up by any accessories.
• Reflectors need to be installed at front (facing forward, color‐less) and rear of bike (facing backwards, red) on pedals and
on spokes on front and rear wheel . If the red rear reflector is installed on seat post and interferes with battery removal,
do as follows: tighten it so that it is installed securely but not overly tight so that it can be twisted to the side to make
space for battery removal. After battery is installed, twist red rear reflector so that it faces backwards.
