Leitner Libelle 2020 - Initial Assembly and Setup; Getting Started: Unpacking and Checks

5
GettingStarted
• First,unpackyourelectricbikecarefully makingsurethatyoudon’tscratchthebikewithsharptoolssuchaspaperknifesor
scissors.
• Keep allpackingmaterial includingthecartonintheunlikelycasethebikehastobere‐packedandshipped.
• Locateallparts:battery,keys,frontwheel,mudguards, charger,seatandseatpost,frontlight,handle‐stem,pedals,tools
andanysmallpartslikenutsorscrewsinsidetheshippingcarton.
• Sometimessmallpartslikenutsorscrewsmaycomelooseduringshippingsobesureand checkthebottomofthecarton
andprotectivewrappingcarefully.PleasenotethateBikes arefragileitems.Althoughweareusingfirstclasscourierservices
andthebikesareprofessionallypackeditmayhappenthattheygetdamagedduringtransit.
• Pleasecheckthebikefordamageandanymissingpartsuponarrivalandletusknowimmediately.Wewillthenworkwith
youonasolutionandshipreplacementpartsassoonaspossible.
Assembly Instructions
• This bicycle hasbeen disassembledfor shipping.To ship the bike, thepedals, frontlight,frontmudguard,seat, front wheel
and sometimes the handlebar maybe loosened or removed.
• Differentpartsofthebikessuchasbrakesandgearsmayneedadjustment.This manualwilllist the steps requiredfor
installation.
• Checkallnutsandboltsonthebike,evenifpartshavealreadybeenassembledbythefactory,tomakesurethattheyare
installedsafely.
• IntheinterestofsafetyItisrecommendedtohavethebikeassembledandadjustedbyabikemechanicandserviced
regularly.
Installationoffrontmudguardandfrontlights
Thispartofforkfacingforward.
(Thetwosocketswiththreadspointing
forwardarenotused.Theyareforinstallation
ofVbrakeswhicharenotneededsincethe
bikeisequippedwithfrontdiscbrakes.)
FixmudguardtoforkhereOnbothsides
Topbolt:firstinsertHeadlight,thenfront
Mudguard,thentightenbolt(referto
additionalpicturebelow)
Brakecallipers(needtofacelefthandside).
Install front light on top part of fork using
bolt (and nut if your model has nut) as
shown in the picture above.
Connect black wire to the“‐” poleatthe
backofthelight.
Connect redwire tothe “+” pole. Makesurethesmallmetalpinsof
thelightareinsertedinto theendingofthewire.
