LIMITEDWARRANTY
andTermsandConditionsSummary
PLEASEKEEP YOURPROOFOFPURCHASE
The following parts are warranted to be free from
manufacturer’s faults for a period of 1year(12
months) starting at the date of purchase: battery,
motor,fork,headset,seatpost,saddle,rims,
kickstand, reflectors, wheel hub, controller, brakes,
lights, bottom bracket, crank set, pedals, cassette,
derailleur, shifter, LCD display, handle‐stem,
handlebar, charger, throttle. 2 years for the frame.
This limited warranty does not cover normal wear
and tear items including but not limited to tires,
inner tubes, cables, or any damage, failure, or loss
caused by improper assembly, set up, storage, or
maintenance. This warranty covers normal use only. It
does not cover damage to the the product due to
misuse, neglect, accident or improper service.
Commercial use, including but not limited to
couriers, bike rentals, flyer deliver and food delivery
will void the warranty. Any modification of the
product without authorization of Leitner will void the
warranty. Warranty is for the original purchaser only.
Warranty is not transferrable to second hand users. It
is the customers' responsibility to service and
maintain the products regularly and to make sure
thattheproductissafetousebeforeeachride.
Leitner does not accept claims for repairs which were
performed without our written approval. Leitner does
not assume any liability to the extent permitted by
the law. For full terms and conditions please visit
Leitner.com.au. Leitner reserves the right to change
warranty terms without notice.
22
Lubrication
Please find short instructions for lubrication below.
Suitable grease and oil should be purchased from local
bike shops. For further information please contact us.
Wipe off any excess oil or grease. Make sure no lubricant
is present on parts where it doesn’t belong.
• Chain: Every month. Use a rag underneath chain to
avoid oil spilling onto other parts and use the rag to
wipe off excess chain oil after lubrication.
• Quill type stem: Every year. Remove stem then
remove grease from wedge. Apply thin layer of grease
to wedge and the part of stem which is inside frame.
Re‐install stem
• Seatpost: Every year remove seatpost, then remove
grease from seatpost. Apply thin layer of grease to
the part of seatpost which is inside frame. Re‐install
seatpost
• Pedal threads on pedal axle where they insert into
crank arms: Every year. Refer to pedal installation
section of this manual to remove pedals, then remove
grease from pedal axle. Apply thin layer of grease to
the threads. Re‐install pedals according to manual.
• Derailleur: Every month. Apply grease to all pivot
points including the pulley.
• Brake lever pivots and brake arm fixing pivots: every
3 months.
• Quick release lever: Every year. Apply light oil to
lever where it turns inside the body.
• Suspension fork: Every month remove old visible
grease and apply a thin layer of grease to visible part
of fork where it moves up and down due to
suspension.
• Brake cable and gear cable: Lubricate when installing
it
The following parts should be lubricated by a local bicycle
professional
• Bottom bracket bearings: Every year
• Direct connect stem: Every year
• Headset bearings: Every year
• Wheel bearings: Every year
• Oil inside Oil suspension fork: Every year.
DO NOT LUBRICATE: Rear suspension shock or pivots,
brake pads, wheel rims, brake discs, pedal surface.
RecommendedTorquevaluesin
NewtonMeter(Nm)unit
Unitconversion:1Nm=8.85Inch‐Pounds
• Boltsattachinghandle‐bartohandle‐stem:18‐20
Nm,FigureFS3
• Boltsattachingbrakelever,throttleandgear
shiftertohandle‐bar:7Nm
• Steerer‐clampboltsonhandle‐stem:18‐20Nm,
FigureFS1andFS4
• Otherboltsonhandle‐stem:10Nm
• Quickreleaseleverattachingseatposttoframe:
15Nm.BushingboltFigureFR1:10Nm
• Brakes:callipermountingbolts:15Nm,Centering
bolts:12Nm,Cableanchorbolt:7Nm,Disc
mountingbolt8Nm,FigureDB1
• Frontwheelquickrelease:Measurementunitin
pounds,notNewtonMeter:between12pounds
and45pounds
• Rimbrakepadclampbolt:9Nm,FigureRB1.
• Rimcableclampbolt:7Nm,FigureRB2.
• Rearwheelnuts:30‐35Nm,FigureRR4.
• Pedalstocrankarm:40Nm
• Crankarmtobottombracket:40Nm
• Boltsonrearrack:16Nm
• SeatRailclampnut:22Nm,FigureS1.
• Cableanchorscrewatrearderailleur:7Nm,
FigureD1
