5.1004.8641.0 B
3-6 Description and Operation
5. Wipe away the feed on the surface that falls out of the cup. (see figure 12 on page 3-5).
After wiping away the excess of feed in front of the cup, the feed will repositioning in the cup.
6. Wipe again the excess of feed that falls out of the cup (see figure 13 on page 3-5).
7. Determine the angle (α°) of the feed in the cup (see figure 14 on page 3-6).
8. Determine the feed suitability (see table 1 on page 3-7).
Use a protractor ruler to determine the angle of the feed in the cup.
Figure 14. Determine the feed angle
in n o vato rs in agriculture
