5.1004.8641.0 B
5-18 Maintenance
Figure 36. Connect the twin tube to the teat cup
KEY: 1. Twin tube - 2. Milk collection cup
3. Clean and dry the milk collection cup (2) (see
figure 36 on page 5-18).
4. Fully connect the twin tube (1) to the milk
collection cup (2) of the teat cup.
Figure 37. Install the first part of the twin tube
cover
KEY: 1. Twin tube - 2. Part of twin tube cover - 3. Part of
twin tube cover
5. Install the (smaller) part (2) of the twin tube
cover over the pulsation tube of the twin tube (1)
(see figure 37 on page 5-18).
in n o vato rs in agriculture
