14
Rear panel
GROUP OUT 1-4
Four JACK unbalanced connectors: allows the group signal to be sent to external devices such as
multitrack recorders or additional sound systems.
48V PHANTOM POWER
+48V Phantom power supply buttons: activates a +48V power supply separately on the MIC inputs 1 to
6 and 7 to 16 (XLR-F connector) of the MONO input channels, allowing condenser microphones and D.I.
boxes to be powered from the mixer.
NOTE
When the PHANTOM power supply is switched on make certain that cables with BALANCED XLR
connectors are ALWAYS used to connect the microphones: this precaution is extremely important for
avoiding damage in the event of both condenser and normal (dynamic) microphones being used
simultaneously. Switch on the phantom power supply only after having connected the condenser
microphone to the input and only with the channel fader closed to avoid output signal peaks.
Mixer on/off switch.
Power supply socket / Main fuse holder
In the event of breaking, always replace the fuse with same type and rating.
