LEMKEN Heliodor 8 - Adjusting the Working Depth

Mounting a LEMKEN Solitair seed drill
83
13.2.2 Adjusting the working depth
The wheelmark eradicators are set to ap-
prox. 5 cm deeper than the bout of the
tractor.
Adjust the working depth of the wheelmark
eradicator as follows:
 Raise the implement to relieve the load-
ing on the wheelmark eradicator (1).
 Release the guide pin (5).
 Hold the wheelmark eradicator (1) with
the hand.
 Pull the guide pin (5) out of the holder
(5).
 Move the wheelmark eradicator (1) to
the desired position.
 Fix the wheelmark eradicator in place in
the holder (4) again using the guide pin
(5).
 Lock the guide pin (5).
5
4
1
