29
DC-4000 PARTS LIST
Nov99
Pos. Part nos. Description Qty.
Pos. Part nos. Description Qty.
L050-001 DC-4000 airless piston pump on cart
L050-003 DC-4000 airless piston pump on stand
1 L050-515 Main housing 1
2 L001-527 Vent plug, M16 1
3 L050-521 Formed housing seal 1
4 L050-514 Bearing (Front) 1
5 L050-513 Cam shaft (15 mm) 1
6 L050-512 Key 1
7 L050-510 Large Gear 1
8 L050-511 Bearing 1
9 L050-509 Bearing (Support) 1
10 Motor gear (included with motor) 1
11 L050-508 Snap ring 1
12 L004-556 Motor bearing, front 1
13 L050-507 Oil seal, motor 1
14 L050-502 Motor Plate 1
15 L050-500 3/4 HP 90 VDC. (110)motor (incl. #12) 1
L050-505 3/4 HP 180 VDC. (220)motor (incl. #12)1
L050-622 Motor decal 1
L001-655 Motor bearing, fan end 1
16 L050-626 DC motor brush (each) 2
17 L050-591 Bolt M4 x 12 (for housing & sensor) 8
19 L035-313 Nylon tubing (1/4" I.D.) cart = 2' 2
L035-313 Nylon tubing (1/4" I.D.) stand = 5' 10" 6
L013-512 Nylon tie 7" 1
20 L035-715 Coupler, 1/4h x 1/4m 1
21 L050-617 18" connection hose 1
22 L032-630 Connector 1/4m x 1/4m BSP 2
23 L050-544 Switch housing (bare) 1
L060-595 Triac 1
L060-596 Bridge rectifier 1
L050-592 Screw M4 x 18 (for triac & rectifier) 3
L001-590 Lock nut, M4 (for triac & rectifier) 3
L050-623 Control box decal 1
24 L036-091 Elbow, 1/4" M 2
25 L050-600 Pressure sensor ass'y(up to s/n 10499)1
L055-531 Fluid manifold w/o sensor (new style) 1
25a L055-532 Mini sensor (new style,s/n 10500 +) 1
L055-534 Seal for mini sensor 1
26 L006-593 Prime/spray valve 1
27 L004-559 Switch, on/off 1
28 L050-588 Circuit breaker 15 amp. (115V version) 1
L050-589 Circuit breaker 8 amp. (220V version) 1
29 L050-590 Knob for potentiometer 1
L050-630 Potentiometer 1
30 L050-605 Circuit board (110V) 1
L050-606 Circuit board (220V) 1
L050-599 Self tap screw (for PC board) 4
L035-356 Wire, white, 14awg stranded 1.5
31 L050-585 Strain relief, 16/3, thin panel 2
32 L005-529 Cable with plug 15' x 16/3 1
L004-560 Connector, F term. insl (blue) 9
L050-586 Connector, F term. insl (yellow) 3
L050-587 Connector, F term. insl (red) 5
L001-520 Connector, ring #8 2
L075-534 Marrette (14-18 awg) 2
35 L050-535 Drain plug 1
36 L001-555 Copper seal 3
40 L001-550 Washer, knurled lock (M10) 5
41 L050-520 Housing bolt, M10 x 1.5 x 16 allen 5
42 L050-519 Oil seal 1
43 L050-526 Rod bearing 1
44 L050-532 Rod bushing 1
45 L050-530 Connecting rod, (incl. Pos 44) 1
46 L050-524 Cover screw, M4 x 10 3
47 L050-523 Front cover 1
48 L050-537 Pail hook 1
49 L050-538 Bolt for hook M6x12 2
50 L050-534 Plunger 1
51 L050-533 Rod pin 1
52 L050-522 Connecting bolt 1
53 L050-540 Bushing (self lube bronze) 1
54 L050-539 Central body bare 1
55 L050-525 Bolt M8 x 60 4
56 L050-542 Grease nipple, M8 1
57 L050-541 Metal guard 1
58 L036-271 Swivel elbow 1/4F x 1/4M 1
60 L050-563 Lock nut 1
61 L050-577 Packing nut 1
62 L050-572 Upper packings (normal stacked) 1
L050-671 Upper packings (1 piece) 1
L050-672 Spacer (for 1 piece packing only) 1
63 L050-562 Pump body 1
64 L050-561 Teflon O-ring 1
65 L050-571 Piston 1
66 L001-593 Cone guide 1
67 L050-569 S.V. ball 1
68 L050-570 S.V. copper seal 1
69 L050-568 S.V. seat 1
70 L050-567 Shaft valve retaining nut 1
71 L050-565 Wavy washer 3
72 L050-566 Lower packings (poly)
L050-673 Lower packings (1 piece) 1
73 L050-564 Spacer, 24mm (for stacked packing) 1
L050-674 Spacer, 39mm (for 1 piece packing) 1
74 L050-582 F.V. ball stop 1
75 L050-581 F.V. ball 1
76 L050-578 Foot valve housing with seat 1
77 L050-583 Suction pipe 1
78 L001-607 Basket screen (Fine, 1/2") 1
80 L002-715 Bolt, Hex (5/16" NC x 1-1/2") 1
81 L005-713 Washer, flat (5/16") 1
82 L002-714 Washer, split lock (5/16") 1
83 L002-713 Nut, Hex (5/16" NC) 1
84 L050-550 Cart (incl pos. 85) 1
85 L050-552 Cart handle 1
86 L002-719 Quick Pin 3" 1
87 L050-553 3/4" plastic cap 2
88 L002-556 Tool box 1
89 L002-815 Nut, 1/4 nc 1
90 L002-817 Flat washer, 1/4 1
91 L002-709 Hex bolt, 1/4 x 3/4 nc 1
92 L002-561 Wheel (20mm shaft Dia.) 2
93 L002-560 Pin, cotter (1/8" x 2") 2
Pump packing kit:
94 L050-625 Packing kit, normal stacked without spacer
consisting of: 62,67,68,72,74,75.
L050-670 Packing kit, 1 piece packings with spacers
consisting of: 62,67,68,72,73,74,75.
Assemblies and accessories:
L050-624 Pressure control assembly(220V)
L050-543 Pressure control assembly(110V)
consisting of: 23-30
L034-124 Gear oil EP90W, liter
L034-125 Packing lubricating oil, squeeze bottle
L050-621 Owner’s manual
95 L001-578 Basket screen, M28 1
96 L001-577 Suction elbow, 5 gallon x 1" 1
97 L035-207 O-clamp 2
98 L035-315 Suction hose per foot 3
99 L035-732 Hose barb fitting 1
100 L036-303 Elbow fitting 1
101 L035-503 Connector fitting 1
103 L035-313 Return hose per foot 5
