8
TIP SELECTION
FAN FAN FLOW TIP
PART NO. ORIFICE AT 1' ANGLE LTR/MIN MARKING
L043-091 .009 2" 10 DEG. 0.26 109
L043-092 .009 4" 20 DEG. 0.26 209
L043-093 .009 6" 30 DEG. 0.26 309
L043-094 .009 8" 40 DEG. 0.26 409
L043-095 .009 10" 50 DEG. 0.26 509
L043-096 .009 12" 60 DEG. 0.26 609
L043-111 .011 2" 10 DEG. 0.40 111
L043-112 .011 4" 20 DEG. 0.40 211
L043-113 .011 6" 30 DEG. 0.40 311
L043-114 .011 8" 40 DEG. 0.40 411
L043-115 .011 10" 50 DEG. 0.40 511
L043-116 .011 12" 60 DEG. 0.40 611
L043-117 .011 14" 70 DEG. 0.40 711
L043-131 .013 2" 10 DEG. 0.60 113
L043-132 .013 4" 20 DEG. 0.60 213
L043-133 .013 6" 30 DEG. 0.60 313
L043-134 .013 8" 40 DEG. 0.60 413
L043-135 .013 10" 50 DEG. 0.60 513
L043-136 .013 12" 60 DEG. 0.60 613
L043-137 .013 14" 70 DEG. 0.60 713
L043-138 .013 16" 80 DEG. 0.60 813
L043-151 .015 2" 10 DEG. 0.80 115
L043-152 .015 4" 20 DEG. 0.80 215
L043-153 .015 6" 30 DEG. 0.80 315
L043-154 .015 8" 40 DEG. 0.80 415
L043-155 .015 10" 50 DEG. 0.80 515
L043-156 .015 12" 60 DEG. 0.80 615
L043-157 .015 14" 70 DEG. 0.80 715
L043-171 .017 2" 10 DEG. 1.0 117
L043-172 .017 4" 20 DEG. 1.0 217
L043-173 .017 6" 30 DEG. 1.0 317
L043-174 .017 8" 40 DEG. 1.0 417
L043-175 .017 10" 50 DEG. 1.0 517
L043-176 .017 12" 60 DEG. 1.0 617
L043-177 .017 14" 70 DEG. 1.0 717
L043-178 .017 16" 80 DEG. 1.0 817
L043-192 .019 4" 20 DEG. 1.3 219
L043-193 .019 6" 30 DEG. 1.3 319
L043-194 .019 8" 40 DEG. 1.3 419
L043-195 .019 10" 50 DEG. 1.3 519
L043-196 .019 12" 60 DEG. 1.3 619
L043-197 .019 14" 70 DEG. 1.3 719
L043-198 .019 16" 80 DEG. 1.3 819
L043-213 .021 6" 30 DEG. 1.6 321
L043-214 .021 8" 40 DEG. 1.6 421
L043-215 .021 10" 50 DEG. 1.6 521
L043-216 .021 12" 60 DEG. 1.6 621
L043-217 .021 14" 70 DEG. 1.6 721
L043-218 .021 16" 80 DEG. 1.6 821
L043-219 .021 18" 90 DEG. 1.6 921
L043-234 .023 8" 40 DEG. 1.9 423
L043-235 .023 10" 50 DEG. 1.9 523
L043-236 .023 12" 60 DEG. 1.9 623
L043-237 .023 14" 70 DEG. 1.9 723
L043-238 .023 16" 80 DEG. 1.9 823
L043-239 .023 18" 90 DEG. 1.9 923
L043-254 .025 8" 40 DEG. 2.3 425
L043-255 .025 10" 50 DEG. 2.3 525
L043-256 .025 12" 60 DEG. 2.3 625
L043-257 .025 14" 70 DEG. 2.3 725
L043-258 .025 16" 80 DEG. 2.3 825
L043-259 .025 18" 90 DEG. 2.3 925
L043-274 .027 8" 40 DEG. 2.7 427
L043-275 .027 10" 50 DEG. 2.7 527
L043-276 .027 12" 60 DEG. 2.7 627
L043-277 .027 14" 70 DEG. 2.7 727
L043-278 .027 16" 80 DEG. 2.7 827
L043-279 .027 18" 90 DEG. 2.7 927
L043-294 .029 8" 40 DEG. 3.1 429
L043-295 .029 10" 50 DEG. 3.1 529
L043-296 .029 12" 60 DEG. 3.1 629
L043-297 .029 14" 70 DEG. 3.1 729
L043-298 .029 16" 80 DEG. 3.1 829
L043-299 .029 18" 90 DEG. 3.1 929
L043-313 .031 6" 30 DEG. 3.5 331
L043-314 .031 8" 40 DEG. 3.5 431
L043-315 .031 10" 50 DEG. 3.5 531
L043-316 .031 12" 60 DEG. 3.5 631
L043-317 .031 14" 70 DEG. 3.5 731
L043-318 .031 16" 80 DEG. 3.5 831
TIP SELECTION:
A standard size .017 tip will give good performance in
latex or oil base materials of moderate viscosities.
The following chart gives a basic idea of what tips the
Lemmer sprayers can handle performance wise and what
tip is appropriate for which material. Gun filter sizing is
also included in the chart for handy reference.
For a much more detailed look at tip sizes, please consult
the detailed tip chart on page 10.
Tip size Paint type Filter size
.011 Lacquers, industrial enamel, red
very thin paints.
.013 Oil stains, pigmented lacquers, yellow
red oxide primer.
.015 Normal application of latex, oil base, yellow
stains and , solid color oil stains.
.017 Fast application of latex paints white
and stains, oil base paints.
.019 Heavier body latex paints. white
.021 Fast application of heavier latex white
paint, smooth block filter when
properly thinned.
.023 Maximum tip on DC-4000/L-1. not req’d
.027 Maximum tip on L-5,000. not req’d
.033 Maximum tip on L-7,500. not req’d
.043 Maximum tip on L-10,000. not req’d
The maximum tip for a pump is the largest tip that will
deliver a proper pressure for spraying without overwork-
ing or overloading. When a tip is used for some period of
time, it can wear beyond the maximum for the pump,
which will cause low pressure and poor spray pattern.
Stains and thick latex products often cause the most rapid
wear of the tip, while clear lacquers and varnishes cause
the least wear. Thus tip life can vary from as little as 50
gallons to as much as 200 or more, depending on the
product being sprayed and the pressure used.
Filters for the gun are picked not because of the type of
paint being used, but to protect a given size of tip. You
pick the tip for the type of paint and job being done and
then choose the filter to protect that tip. The chart on
page 10 gives much more detail about tip and filter
choices.
THE TWO MOST IMPORTANT THINGS TO REMEM-
BER ABOUT TIPS.....
1) Low pressure means longer life, for tips and the
pump. Less overspray too!
2) Worn tips waste paint and overwork the pump,
wearing it out quickly.
