44
TFT screen size 10.2 inches
Screen resolution 800x480
Laser Wavelength 780/650nm
TV System PAL B/G, SECAM L’/L, PAL D/K or PAL I
Frequency Response 20Hz
-
20kHz ±2.5dB
Audio Signal-to-noise Rate ≥85dB
Audio distortion + noise ≤ -70dB (1kHz)
Channel Separation ≥70dB (1kHz)
Dynamic Range ≥80dB (1kHz)
Audio Out Out Level 2V±
0.2
1.0
, Load 10kΩ
Video Out
Out Level 1V
P-P
±0.2, Load 75Ω
Unbalanced Negative
Power AC100
240V50/60Hz
Dimensions 268×120×257mm
Weight Approximate 2.2 Kg
DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
Confidential unpublished works.
©
1992 -1997 Dolby Laboratories, Inc.
All rights reserved.
Specifications
