14ACX SERIES
Model Numbers Label Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
14ACX-036-230-01 1.0 30 18.7 14.1 77.0 1/6 825 1.1 2.1
14ACX-036-230-02 1.0 30 18.7 14.1 77.0 1/6 825 1.1 2.1
14ACX-036-230-10 1.0 30 18.7 14.1 77.0 1/6 825 1.1 1.9
14ACX-036-230-11
1.0 30 18.7 14.1 77.0 1/6 825 1.1 1.9
1.0 30 18.6 14.1 77.0 1/6 825 1.0 1.9
14ACX-036-230-13 1.0 & 2.0 30 18.7 14.1 77.0 1/6 825 1.1 1.9
14ACX-036-230-14
1.0 & 2.0 30 18.7 14.1 77.0 1/6 825 1.1 1.9
3.0 30 18.6 14.1 77.0 1/6 825 1.0 1.9
14ACX-036-230-15
1.0 & 2.0 30 18.7 14.1 77.0 1/6 825 1.1 1.9
3.0 & 4.0 30 18.6 14.1 77.0 1/6 825 1.0 1.9
14ACX-036-230-16 1.0 30 18.6 14.1 77.0 1/6 825 1.0 1.9
1
HACR type circuit breaker or fuse.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
208/230V-60 Hz-1 Ph
Model Numbers Label Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
14ACX-041-230-01 1.0 & 2.0 35 22.8 16.7 79.0 1/4 825 1.7 3.2
14ACX-041-230-02 1.0 & 2.0 35 22.8 16.7 79.0 1/4 825 1.7 3.2
14ACX-041-230-03
1.0 35 22.8 16.7 79.0 1/4 825 1.7 3.2
2.0 35 22.6 16.7 79.0 1/4 825 1.7 3.2
1
HACR type circuit breaker or fuse.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
208/230V-60 Hz-1 Ph
Model Numbers Label Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
14ACX-042-230-01 1.0 40 24.1 17.9 112.0 1/4 825 1.7 3.2
14ACX-042-230-10 1.0 40 24.1 17.9 112.0 1/4 825 1.7 3.2
14ACX-042-230-11 1.0 & 2.0 40 24.1 17.9 112.0 1/4 825 1.7 3.2
14ACX-042-230-12 1.0 & 2.0 40 24.1 17.9 112.0 1/4 825 1.7 3.2
14ACX-042-230-13 1.0 40 24.1 17.9 112.0 1/4 825 1.7 3.2
14ACX-042-230-14 1.0 40 24.1 17.9 112.0 1/4 825 1.7 3.2
1
HACR type circuit breaker or fuse.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
208/230V-60 Hz-1 Ph
Model Numbers Label Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
14ACX-047-230-01 1.0 45 26.7 19.9 109.0 1/3 825 1.8 2.9
14ACX-047-230-02 1.0 & 2.0 45 26.7 19.9 109.0 1/3 825 1.8 2.9
14ACX-047-230-03 1.0 45 26.7 19.9 109.0 1/3 825 1.8 2.9
1
HACR type circuit breaker or fuse.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
