Lennox 14ACX - Page 6

Page 6
208/230V-60 Hz-1 Ph
Model Numbers Label Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
14ACX-048-230-01 1.0 50 29.0 21.8 117.0 1/4 825 1.7 3.1
14ACX-048-230-10 1.0 50 29.0 21.8 117.0 1/4 825 1.7 3.1
14ACX-048-230-11 1.0 & 2.0 50 29.0 21.8 117.0 1/4 825 1.7 3.1
14ACX-048-230-12 1.0 & 2.0 50 29.0 21.8 117.0 1/4 825 1.7 3.1
14ACX-048-230-13 1.0 50 29.0 21.8 117.0 1/4 825 1.7 3.1
14ACX-048-230-16 1.0 45 26.6 19.9 109.0 1/4 825 1.7 3.2
14ACX-048-230-17 1.0 45 26.6 19.8 96.0 1/4 825 1.7 3.2
1
HACR type circuit breaker or fuse.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
208/230V-60 Hz-1 Ph
Model Numbers Label Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
14ACX-059-230-01
1.0, 2.0,
3.0, 4.0 &
5.0
50 33.1 25.0 134.0 1/3 825 1.8 2.9
14ACX-059-230-02 1.0 & 2.0 50 33.1 25.0 134.0 1/3 825 1.8 2.9
14ACX-059-230-03 1.0 50 33.1 25.0 134.0 1/3 825 1.8 2.9
14ACX-059-230-04 1.0 & 2.0 50 34.1 25.0 134.0 1/3 820 2.8 ----
1
HACR type circuit breaker or fuse.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
208/230V-60 Hz-1 Ph
Model Numbers Label Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
14ACX-060-230-01 1.0 60 34.8 26.4 134.0 1/3 825 1.8 2.9
14ACX-060-230-10 1.0 60 34.8 26.4 134.0 1/3 825 1.8 2.9
14ACX-060-230-11 1.0 60 34.8 26.4 134.0 1/3 825 1.8 2.9
14ACX-060-230-12 1.0 & 2.0 60 34.8 26.4 134.0 1/3 825 1.8 2.9
14ACX-060-230-13 1.0 & 2.0 60 34.8 26.4 134.0 1/3 825 1.8 2.9
14ACX-060-230-14 1.0 60 34.8 26.4 134.0 1/3 825 1.8 2.9
14ACX-060-230-15 1.0 60 34.8 26.4 134.0 1/3 825 1.8 2.9
1
HACR type circuit breaker or fuse.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
