Page 7
14ACX SERIES
Unit Dimensions - Inches (mm)
SUCTION AND LIQUID
LINE CONNECTION
DISCHARGE AIR
SIDE VIEW
OUTDOOR
COIL FAN
COMPRESSOR
A
B
A
OPTIONAL UNIT STANDOFF KIT (4)
(FIELD INSTALLED)
SIDE VIEW
Model Numbers A B
14ACX-018-230-XX (All) 24-1/4 (616) 29-1/4 (743)
14ACX-024-230-01 24-1/4 (616) 29-1/4 (743)
14ACX-024-230-02 through -12 28-1/4 (724) 33-1/4 (845)
14ACX-024-230-13 28-1/4 (724) 29-1/4 (743)
14ACX-030-230-01 28-1/4 (724) 29-1/4 (743)
14ACX-030-230-02 and later 28-1/4 (724) 37-1/4 (946)
14ACX-036-230-01 28-1/4 (724) 29-1/4 (743)
14ACX-036-230-02 and later 28-1/4 (724) 37-1/4 (946)
14ACX-041-230-01 28-1/4 (724) 37-1/4 (946)
14ACX-042-230-XX (All) 28-1/4 (724) 29-1/4 (743)
14ACX-047-230-01 32-1/4 (819) 33-1/4 (845)
14ACX-048-230-1 through -14 28-1/4 (724) 37-1/4 (946)
14ACX-048-230-15 28-1/4 (724) 33-1/4 (845)
14ACX-059-230-XX (All) 32-1/4 (819) 37-1/4 (946)
14ACX-060-230-XX (All) 32-1/4 (819) 33-1/4 (845)
